Wind Turbine 3 KW
3 KW Wind Power Plant (AIA-KW3)
| Measured Output | 3 KW |
| Maximum Output | 3.5 KW |
| Output Voltage | 24V – 48V |
| Blade Height | 1 m |
| Rotor Diameter | 0.8 m |
| Starting Wind Speed | 1.2 m/s |
| Nominal Wind Speed | 10 m/s |
| Rated Wind Speed | 45 m/s |
| Generator | Permanent Magnet Generator |
| Generator Efficiency | >0.96 |
| Turbine Weight | 52 kg |
| Noise Level | <10db |
| Temperature Range | -35°C to +60°C |
| Design Lifecycle | 20 years |
| Warranty | Standard 2 years |
- High aerodynamic efficiency under various wind conditions.
- Excellent performance in multidirectional, turbulent, upward, slow, and gusty wind conditions.
- No external braking system required: The unique rotor aerodynamics and self-regulating speed enable maximum energy generation even at high wind speeds.
- Low maintenance: Only one annual service is required.
- Extremely quiet operation: At a wind speed of 6 m/s, the sound level is below 10 dBA – ideal for urban and private areas.
- Flexible roof or ground installation, suitable for off-grid and grid-connected solutions.
- Slow rotational speed (80–100 RPM) protects wildlife and components. Additionally, rotor surfaces are ideal for advertising and sponsorship platforms.
Wind Turbine Calculator
Calculate energy production at different wind speeds:
The energy production in kWh is calculated as an approximate annual value.
*The information provided is approximate and depends on location and wind strength
You can check the wind speeds for your location on this page: www.vortexfdc.com
PDF Catalog
Arico Energy – Wind Turbine
Arico Energy is an internationally active Swiss company specializing in the development, production, and marketing of innovative, decentralized energy solutions.
You can find out more in our brochure.
You can find out more in our brochure.
Frequently Asked Questions
FAQ – General Questions about Wind Turbines
A wind turbine converts the kinetic energy of the wind into electrical energy. The wind turns the rotor blades, which are connected to a generator. The generator converts the mechanical energy into electricity, which can be used to power your devices or fed into the grid.
A wind turbine offers numerous benefits:
- Renewable Energy: Generate clean electricity from wind power, contributing to climate protection.
- Independence: Reduce reliance on energy providers and shield yourself from rising energy prices.
- Cost Savings: Lower your electricity bills by using the power you generate.
- Sustainability: Long lifespan and low operational costs make wind turbines a sustainable investment.
Yes, modern wind turbines are designed to generate electricity even in low or gusty wind conditions. Thanks to their aerodynamic efficiency, they can harness multidirectional and turbulent winds. At very high wind speeds, the turbine automatically regulates its rotation speed to prevent damage.
The installation of a wind turbine involves several steps:
- Consultation and Site Analysis: We assess whether your location is suitable for a wind turbine.
- Planning: We create a detailed plan based on your requirements and local wind conditions.
- Permits: If necessary, we handle all permit applications.
- Installation and Commissioning: Our team sets up the turbine and ensures it’s ready for operation.
An ideal location for a wind turbine should have consistent wind availability. Open, unobstructed areas away from tall buildings or trees are optimal. Additionally, local building regulations must be observed.
Modern wind turbines are built to withstand extreme weather conditions. At very high wind speeds, they automatically reduce their rotation speed or shut down to prevent damage. Many turbines are also designed with materials that ensure functionality at low temperatures.
A wind turbine typically lasts 20 to 25 years. With regular maintenance and care, it can continue generating electricity efficiently for even longer.
The cost of a wind turbine depends on factors like its size, location, and installation requirements. Small systems for private households start at around €10,000, while larger commercial systems can be significantly more expensive.
